Molex 39281163 Mini-fit Jr 16-pin Sil Socket 4.2mm Pitch Dual Row

Molex
Order Code:

05-3525

Brand: Molex MPN: 39281163 EAN-13: 2050007107262

Discontinued


The Molex Built-in SIL socket is a standard socket with 16 pins and a contact spacing of 4.2 mm. This component is typically used in electronic applications requiring reliable single in-line connections. Common uses include interfacing with circuit boards in consumer electronics and industrial equipment.
Type Built-in SIL socket (standard)
Number of Positions 16
Number of Rows 2
Orientation Perpendicular (to the PCB)
Contact Plating Tin
Board contact surface Tin
Case Material Nylon (NL)
Coating thickness (PCB side) 0.889µm
Colour Ecru
Connection Soldering
Connector coating thickness 0.889µm
Cross Section 4.2mm
Engineering Part No 5566-16A
Engineering Series Name MINIFIT JR HDR VERT
Engineering Series No 05566
Max. temperature +105°C
Min. temperature -40°C
Nominal Current 9A
Nominal Voltage 600V
Packaging Type Bag
