Molex 26202081 KK 396 Pin Strip 8 Pins 3.96mm Wire-to-board Header

Image Representative of Range

Molex 26202081 KK 396 Pin Strip 8 Pins 3.96mm Wire-to-board Header

Molex
Order Code:

05-3310

Brand: Molex MPN: 26202081 EAN-13: 2050008564705
Qty Unit Price (Ex VAT)
10+ £0.690
100+ £0.616
375+ £0.593
1500+ £0.567
3000+ £0.547
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
39 in stock, despatched in 4 working days

Molex manufactures the pin strip (standard) with part number 26202081, featuring 8 pins and a contact spacing of 3.96 mm. This component is typically used in electronic connections for securing and providing paths for electric current. It is commonly utilised in circuit boards and electronic devices.
Type Pin strip (standard)
Number of Positions 8
Pitch 3.96mm
Number of Rows 1
Application Board-to-Board, Power, Wire-to-Board
Base unit of measure PC
Base unit of measure desc piece
Breakaway No
China ro h s status Compliant per SJ/T 11365-2006
Circuits loaded 8
Circuits maximum 8
Colour resin Natural
Component type PCB Header
Connection Print
Connector orientation Perpendicular (to the PCB)
Cross Section 3.96mm
Current maximum per contact 7.0A
Delivery unit 1800
Design registration eligibility false
Durability mating cycles max 25
Duration at max process temperature seconds 5
ELV status Not Relevant
Engineering number 319208A
Engineering Part No 319208A
Engineering Series Name .156 RND WIRE STR HD
Engineering Series No 03192
First mate last break No
First published date 2007-06-05
Flammability 94V-2
G a d s l/ i m d s Not Relevant
Glow wire capable No
Guide to mating part No
H f l h status Low-Halogen per IEC 61249-2-21
Keying to mating part No
Lead free process capability WAVE
Lock to mating part No
Material metal Brass
Material plating mating Tin
Material plating termination Tin
Material resin Nylon
Material type Finished Goods
Max cycles at max process temperature 1
Minimum line quantity 9000
Net weight 1.946/g
Orientation Vertical
Packaging Type Bulk
Pc tail length 4.45mm
Pcb locator No
Pcb retention No
Pcb thickness recommended 1.60mm
Pitch mating interface 3.96mm
Pitch termination interface 3.96mm
Plating min mating 5.080µm
Plating min termination 5.080µm
Polarized to mating part No
Polarized to pcb No
Primary pack qty 300
Process temperature max c 235
Product name KK 396
Product number display 26202081
Product number hyphen 26-20-2081
Product number sap 0026202081
Reach status Not Contained per D(2025)4165-DC (25 June 2025)
Reference series 3192
Ro h s status Compliant per EU 2015/863
Sampleable True
Shrouded No
Stackable Yes
Taxonomy PCB Headers and Receptacles
Temperature range operating See Product Specification
Termination interface style Through Hole
Ul E29179
Upc 800753734982
Voltage maximum 250V
