The Finder 6M.BU.0.024.2200 is a current converter designed with a Rogowski coil for precise AC current measurement. It facilitates integration into systems by outputting a standard 4-20 mA current loop signal. This device is ideal for applications requiring accurate current monitoring, such as in industrial automation and energy management systems.
| Type |
Gateway |
| Appendant operation agent (Ex ia) |
false |
| Appendant operation agent (Ex ib) |
false |
| Colour |
White |
| Degree of protection (IP) |
IP20 |
| Depth |
63.2mm |
| Dim |
(L x W x H) 63.20 x 17.70 x 93.10 mm |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Fieldbus connection over separate bus coupler possible |
false |
| Front built-in possible |
false |
| Height |
93.10mm |
| IO link master |
false |
| Length |
63.20mm |
| Mobile communication standard 2G (GSM) |
false |
| Mobile communication standard 3G (UMTS) |
false |
| Mobile communication standard GPRS |
false |
| Performance level according to EN ISO 13849-1 |
None |
| Rack-assembly possible |
false |
| Radio standard Bluetooth |
false |
| Radio standard eGPRS |
false |
| Radio standard LTE |
false |
| Radio standard WLAN 802.11 |
false |
| SIL according to IEC 61508 |
None |
| Suitable for rail mounting |
true |
| Suitable for safety functions |
false |
| Supply voltage AC 50 Hz |
24 - 24V |
| Supply voltage AC 60 Hz |
24 - 24V |
| Supply voltage DC |
24 - 24V |
| Supporting protocol for ASI |
false |
| Supporting protocol for AS-Interface Safety at Work |
false |
| Supporting protocol for CAN |
false |
| Supporting protocol for Data-Highway |
false |
| Supporting protocol for DeviceNet |
false |
| Supporting protocol for DeviceNet Safety |
false |
| Supporting protocol for EtherNet/IP |
false |
| Supporting protocol for Foundation Fieldbus |
false |
| Supporting protocol for INTERBUS |
false |
| Supporting protocol for INTERBUS-Safety |
false |
| Supporting protocol for KNX |
false |
| Supporting protocol for LON |
false |
| Supporting protocol for Modbus |
true |
| Supporting protocol for other bus systems |
false |
| Supporting protocol for PROFIBUS |
false |
| Supporting protocol for PROFINET CBA |
false |
| Supporting protocol for PROFINET IO |
false |
| Supporting protocol for PROFIsafe |
false |
| Supporting protocol for SafetyBUS p |
false |
| Supporting protocol for SERCOS |
false |
| Supporting protocol for SUCONET |
false |
| Supporting protocol for TCP/IP |
true |
| System accessory |
false |
| Voltage type (supply voltage) |
AC/DC |
| Wall mounting/direct mounting |
false |
| Width |
17.70mm |
| With potential separation |
true |
