Finder 6K.04.9.024.4709 mini industrial contactor 4 kW 24 V DC 9 A

The Finder 6K.04.9.024.4709 industrial relay is a reliable electrical contactor with three makers and one breaker, supporting up to 4 kW and 24 V DC at a current of 9 A. It is ideal for controlling electrical circuits in industrial environments, ensuring efficient operation and safety. Suitable applications include motor controls and other automated systems requiring precise electrical switching.

Type	Industrial relay
Coil Voltage	24V DC
Contact Current Rating	9A
Contact Material	AgSnO2
Current load	9A
Depth	45mm
Dimensions	(W x H x D) 45 x 57.50 x 45 mm
Height	57.50mm
IP Rating	IP20
Maximum Temperature	+70°C
Min. temperature	-40°C
Number of auxiliary contacts as normally closed contact	1
Number of auxiliary contacts as normally open contact	1
Number of normally closed contacts as main contact	3
Number of normally open contacts as main contact	N/A
Power	4kW
Power Rating	4
Rated control supply voltage DC	24 - 24V
Rated operation current Ie at AC-1, 400 V	N/A
Rated operation current Ie at AC-3, 400 V	9A
Rated operation current Ie at AC-4, 400 V	9A
Rated operation power at AC-3, 400 V	4kW
Rated operation power at AC-4, 400 V	4kW
Rated operation power NEMA	N/A
Suitable for distribution board	true
Type of electrical connection of main circuit	Rail connection
Voltage type for actuating	DC
Width	45mm
