Finder 38.61.0.024.0060 Relay Module 6A SPDT-CO 24VAC AgNi

An AC/DC SPCO relay interface module with a coil voltage of 24V, AgNi + Au contacts and screwless terminals. Suitable for a variety of applications such as industrial automation, air conditioning systems, automatic gates, elevators, etc.

• 35mm Rail mounting
• Instant removal of relay using plastic retaining clip
• CSA, UL VDE approvals

Type	Relay component
Coil Current	6A
Coil Voltage (DC)	24V AC
Complete with socket	true
Contact Configuration	SPDT-CO
Degree of protection (IP)	IP20
Depth	72.5mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	76mm
IP Rating	IP20
Length	93.6mm
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Untreated
Maximum Temperature	+70°C
Min. temperature	-40°C
Mounting Type	Rail
Nominal Current	6A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Operating Temperature	-40 to +70°C
Rated control supply voltage AC 50 Hz	24 - 24V
Rated control supply voltage AC 60 Hz	24 - 24V
Rated control supply voltage DC	24 - 24V
Switching Current Max	6A
Switching Power	1500VA
Switching Voltage Max (AC)	400V AC
Type of electric connection	Spring clamp connection
Type of switch contact	Single contact
Voltage type for actuating	N/A
Width	6.2mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	true
