Finder 38.52.7.024.5050 Crossbar Switch 24V DC 8A 2 change-overs DIN Rail

The Finder 38.52.7.024.5050 is an interface relay with a crossbar switch, operating at 24 V DC and capable of handling 8 A with two change-overs. It is ideal for use in industrial automation and control systems. The robust design ensures reliable performance in switching and protecting electrical circuits.

Type	Crossbar switch
Complete with socket	true
Connection	Screw terminal
Contact Type	2 change-overs
Degree of protection (IP)	IP20
Depth	77.1mm
Dim	(W x H x D) 14 x 89.7 x 77.1 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	89.7mm
IP Rating	IP20
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Gold
Nominal Current	8A
Nominal Voltage	24V DC
Number of contacts as change-over contact	2
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	24 - 24V
Switching current (max.)	8A
Type of electric connection	Screw connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	14mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	true
