Finder 22.74.0.230.1310 Remote Switch 4 makers 230V 1pc

The Finder 22.74.0.230.1310 is an electrical contactor operating at 230 V, designed for remote switch applications. Manufactured by Finder, it is suitable for controlling various electrical circuits. This component is typically used in systems requiring automated switching, such as lighting control and industrial automation.

Type	Remote switch
Coil Voltage	230V
Additional equipment possible	true
Built-in depth	N/A
Contact Current Rating	32A
Contact Material	Ag/Ni (hard silver)
Contact Type	4 makers
Degree of protection (IP)	IP20
Durability	10000000
EF004723	N/A
Hum-free	false
IP Rating	IP20
Max. incandescent lamp load	2500W
Max. load fluorescent lamp	N/A
Max. load fluorescent lamp (Duo circuit)	N/A
Max. load fluorescent lamp (parallel compensated)	N/A
Max. switching capacity	6VA
Max. temperature	+55°C
Min. temperature	-15°C
Mounting Style	DIN rail
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	4
Permanent current (max.)	32A
Power Rating	6
Rated excitation voltage	195.5 - 253V
Rated operating voltage	230 - 230V
Rated operation current	32A
Slider for hand switch	N/A
Switching voltage (max.)	230V AC
Voltage type (excitation voltage)	AC/DC
Voltage type (operating voltage)	AC
Width	17.5mm
Width in number of modular spacings	N/A
With day/night function	N/A
