Finder 22.64.0.024.4310 Relay IP20

This Finder 63A Modular Contactor Relay is from the 22 Series. The relay is supplied with the 24V coil voltage and all NO contact configurations. The relay has a protective separation (reinforced insulation) between coil and contacts and is 35mm DIN rail mountable. The relay is ideal for high inrush current loads up to 240A.

• Voltage: 24V
• Nominal current: 63A
• Switching voltage: 1000mW
• Protection type: IP20
• Ambient temperature: -5°C to +55°C
• Dielectric strength: 2000V AC
• Contact type: All NO
• Switch-on current: (10 ms) 300A
• Dimensions: 63.1(W) x 95.8(H) x mm
• Manufacturer's part: Finder 22.64.0.024.4310
