The Finder 22.34.0.230.1640 contactor is a hum-free control device designed for use with 230 V DC and AC circuits, supporting up to 25 A. It features two makers, two breakers, and includes an auxiliary switch for added functionality, suitable for rail mounting. This electrical contactor is ideal for applications in automation systems where reliable switching and noise reduction are essential.
| Type |
Contactor |
| Coil Voltage |
230V AC |
| Additional equipment possible |
true |
| Ambient temperature |
-20 - +50°C |
| Built-in depth |
N/A |
| Connection |
Screw terminal |
| Contact Current Rating |
(30/110/220 V) 25/5/1 |
| Contact Material |
AgNi |
| Contact Voltage Rating |
250 V/AC/ 440 |
| Current load |
25A |
| Degree of protection (IP) |
IP20 |
| Depth |
60.8mm |
| Dimensions |
(W x H x D) 35 x 84 x 60.8 mm |
| Durability |
30 x 103 switching operations |
| EF004723 |
N/A |
| Electrical lifespan |
2 x 106 switching operations |
| Fall Time |
40ms |
| Height |
84mm |
| Hum-free |
false |
| IP Rating |
IP20 |
| Max. incandescent lamp load |
800W |
| Max. load fluorescent lamp |
200VA |
| Max. load fluorescent lamp (Duo circuit) |
N/A |
| Max. load fluorescent lamp (parallel compensated) |
N/A |
| Max. switching capacity |
6250VA |
| Max. temperature |
+50°C |
| Min. temperature |
-20°C |
| Mounting Style |
Screw terminal |
| Nominal current (details) |
(AC-7b, AC-7c) 10A |
| Number of contacts as normally closed contact |
2 |
| Number of contacts as normally open contact |
2 |
| Power Rating |
6250 |
| Rated excitation voltage |
176 - 264V |
| Rated operating voltage |
250 - 250V |
| Rated operation current |
25A |
| Response Time |
18ms |
| Slider for hand switch |
N/A |
| Switching Capacity |
(AC1/AC-7a) 6250 VA/(AC15, 230 V/AC) 1800VA |
| Switching Current |
(30/110/220 V) 25/5/1A |
| Switching Voltage |
250 V/AC/ 440V AC |
| Switching voltage (max.) |
440V AC |
| Terminals |
Screw terminal |
| Voltage type (excitation voltage) |
AC/DC |
| Voltage type (operating voltage) |
AC |
| Width |
35mm |
| Width in number of modular spacings |
2 |
| With day/night function |
N/A |
