FCI 75915-310LF SIL Socket Std 1 Row 10 Pins 1pc

Image Representative of Range

FCI 75915-310LF SIL Socket Std 1 Row 10 Pins 1pc

FCI
Order Code:

03-0832

Brand: FCI MPN: 75915-310LF EAN-13: 2050003700658
Qty Unit Price (Ex VAT)
5+ £1.09
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
179 in stock, despatched in 4 working days

FCI manufactures the SIL socket 75915-310LF, featuring one row with 10 pins. It is part of the Dubox, PV, and Bergstik series, commonly used in standard receptacles. This component is ideal for applications requiring reliable electrical connections in electronic equipment.
Case Material Thermoplastic UL94V-O
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector Type Power strip, straight
Contact Material Phosphor bronze
Contact surface Nickel plated
CS 2.54mm
Dim (L x W x H) 25.32 x 2.5 x 8.5 mm
Factory colour Blue
Height 8.5mm
Industrial packaging No
Length 25.32mm
Max. temperature +125°C
Min. temperature -65°C
Misc Attribute Dubox / PV / Bergstik
Nominal Current 3A
Nominal current - rounded value 3A
Number of Rows 1
Pin shape Rectangular
Pins per row 10
Separable No
Total number of pins 10
Type Receptacles (standard)
Width 2.5mm
