econ connect WS40W Pin Strip 40 pins 2 rows 1pc

Image Representative of Range

econ connect WS40W Pin Strip 40 pins 2 rows 1pc

econ connect
Standard range
Order Code:

02-7763

Brand: econ connect MPN: WS40W
Qty Unit Price (Ex VAT)
1+ £0.501
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
70 in stock, despatched in 4 working days

The econ connect WS40W pin strip is a component from econ connect featuring a total of 40 pins arranged in 2 rows. Typical applications for this pin strip include use in electronic connectors and circuit board interfaces. This component is ideal for projects requiring precise and reliable pin connections.
Case material PA
Certification marks DIN 41 651
Connection Print
Connector orientation Parallel (to the PCB)
Connector type Pin strip, right angle
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (L x W x H) 12 x 58.4 x 13.8 mm
Factory colour Black
Height 13.8mm
Length 12mm
Manufacturer part # WS40W
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute WS40W
No. of rows 2
Nominal current 1A
Nominal current - rounded value 1A
Nominal voltage 500V AC
Number of pins 40
Pins per row 20
RoHS-compliant Yes
Total no. of pins 40
Type Pin strip
Width 58.4mm
