econ connect PSL3W Pin Strip 3 pins with 2.54 mm contact spacing

Image Representative of Range

econ connect PSL3W Pin Strip 3 pins with 2.54 mm contact spacing

econ connect
Standard range
Order Code:

02-7555

Brand: econ connect MPN: PSL3W
Qty Unit Price (Ex VAT)
1+ £0.067
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
759 in stock, despatched in 4 working days

The econ connect Pin strip (standard) is features three pins with a contact spacing of 2.54 mm. This component is suitable for connecting circuit boards in electronics projects. It is typically used in prototyping and custom connector solutions.
Actuation direction Parallel (to the PCB)
Board contact surface Tin plated
Case material Polyamide
Connection Print
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector type Pin strip, right angle
Contact material Copper alloy
CS 2.54mm
Dim (L x W x H) 19.14 x 16.90 x 7.62 mm
Factory colour Beige
Height 7.62mm
Industrial packaging No
Insulation material Polyamide
Length 19.14mm
Manufacturer part # PSL3W
Max. temperature +85°C
Min. temperature -25°C
Misc Attribute PSL3W
No. of rows 1
Pin Ø 1.02mm
Pin shape Rectangular
Pins per row 3
RoHS-compliant Yes
Total number of pins 3
Type Pin strip (standard)
Width 16.90mm
