econ connect H4CD6 Pin Housing Cable 6 pins 4.2mm spacing 1pc bulk

The econ connect H4CD6 pin housing cable is designed with a total of six pins and features a contact spacing of 4.2 mm. Manufactured for secure and reliable connections, this component is typically used in electrical and electronic applications that require stable pin configurations. With its durable housing, the H4CD6 is suitable for both domestic and industrial environments.

Type	Pin housing cable
Pitch	4.2mm
Number of Ways	6
Number of Rows	2
Mounting Type	Cable mount
Mounting Direction	Straight
Case Material	Nylon (NL)
Colour	White
Connection	Push-fit
Connector System	wire-to-board
Connector Type	Enclosure
CS	4.2mm
Dimensions	(W x H) 11.70 mm x 24 mm
Height	24mm
Maximum Temperature	85°C
Min. temperature	-25°C
Nominal Current	7A
Nominal current - rounded value	7A
Nominal Voltage	600V
Packaging Type	Bulk
Pins per row	3
Width	11.70mm
