The Eaton T0-2-15432/E is a limit switch with a 20 A capacity at 690 V, featuring a 2 x 60° actuator in grey and black. Manufactured by Eaton, this rotary cam switch can be used as a reversing switch, changeover switch, or selection switch. It is typically used in applications requiring precise control and switching in electrical circuits.
| Type |
Limit switch |
| Number of Positions |
2 |
| Complete device in housing |
FALSE |
| Connection |
Screws |
| Degree of protection (IP), front side |
IP65 |
| Degree of protection (NEMA), front side |
12 |
| Device construction |
Built-in device |
| Dim |
(L x W) 48 mm x 48 mm |
| Front shield size |
48x48 mm |
| Functions |
latch |
| IP Rating |
IP65 |
| Length |
48mm |
| Max. rated operation voltage Ue AC |
690V |
| Max. temperature |
+50°C |
| Min. temperature |
-25°C |
| Misc Attribute 1 |
Control Switch Installation |
| Misc Attribute 2 |
T0-2-15432/E |
| Mounting Type |
Recess-mount |
| Number of Pins |
2 |
| Number of Switch Positions |
3 |
| Operation type |
Toggle |
| Power |
6.5kW |
| Print motif |
Manual/0/Auto |
| Rated permanent current Iu |
20A |
| Suitable for distribution board installation |
FALSE |
| Suitable for floor mounting |
FALSE |
| Suitable for front mounting |
TRUE |
| Suitable for intermediate mounting |
FALSE |
| Switching angle |
2 x 60 ° |
| Switching current (max.) |
20A |
| Switching Voltage |
690V |
| Thread Size |
M3.5 |
| Type of control element |
Toggle |
| Type of switch |
Reverser |
| Width |
48mm |
| Width in number of modular spacings |
0 |
| With retraction in 0-position |
FALSE |
| With zero (off) position |
TRUE |
