Eaton 199181 PKZM0 Overload relay 690V AC 1A 1pc

The Eaton 199181 Overload Relay is designed to protect electrical circuits with a capacity of 690 V AC and current rating of 1 A. It serves as a safety switch, offering protection against overloads and ensuring circuit reliability. Typical applications include industrial settings where it safeguards motors and other electrical equipment.

Type	Motor Ptotection Circuit-Breaker
Number of Poles	3
Rated operation power at AC-3, 230 V	N/A
Colour	Multicolour
Dim	(W x H) 45 mm x 93 mm
Durability	0.1 x 106
Height	93mm
Maximum Temperature	+55°C
Min. temperature	-25°C
Misc Attribute 1	PKZM0-1-SPI16
Misc Attribute 2	3-pin
Switching current (max.)	1A
Switching current (min.)	1A
Switching Voltage	690V AC
Width	45mm
