Eaton 197215 EASY-E4 PLC controller 12 inputs/outputs AC powered

The Eaton 197215 EASY-E4-AC-12RC1 PLC controller is a versatile product typically used for automating processes in industrial and commercial settings. It features easy programming, real-time clock functions, and multiple input/output capabilities. This programmable logic controller is ideal for tasks such as building automation, machinery control, and process optimisation.

Type	PLC controller
Dim	(L x W x H) 58 x 71.5 x 90 mm
Fitting type (details)	DIN rail IEC/EN 60715, 35 mm or screw mounting with mounting brackets ZB4-101-GF1 (accessories)
Height	90mm
IP rating	IP20
Length	58mm
Manufacturer part #	197215
Max. ambient temperature	+55°C
Max. operating voltage	240V DC/AC
Min. ambient temperature	-25°C
Min. operating voltage	120V DC/AC
Misc Attribute	EASY-E4-AC-12RC1
No. of Analogue Inputs	0
No. of Analogue Outputs	0
No. of digital inputs (max.)	8
Operating voltage	120 - 240 V DC/AC
Weight	0
Width	71.5mm
