Eaton manufactures the 106821 LS-S02-230AFT-ZBZ/X safety button, which operates at 400 V and 6 A. It features an IP65 rating, indicating high protection against dust and water, making it suitable for industrial environments. This safety button is typically used for emergency power-off applications in machinery and equipment systems.
| Type |
Safety button |
| IP Rating |
IP65 |
| Alignment of the control element |
Other |
| Ambient temperature during operating |
-25-70°C |
| Coating housing |
Other |
| Connection |
Spring-loaded heavy duty connector |
| Construction type housing |
Cuboid |
| Contact Type |
2 breakers |
| Degree of protection (IP) |
IP65 |
| Degree of protection (NEMA) |
Other |
| Depth |
37.8mm |
| Diameter sensor |
0mm |
| Dim |
(L x W x H) 39 x 60 x 173 mm |
| Durability |
>1 x 10 6 cycles |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Forced opening |
TRUE |
| Height |
173mm |
| Height of sensor |
173mm |
| Housing Material |
Plastic |
| Length |
39mm |
| Length of sensor |
39mm |
| Material |
Plastic |
| Max. temperature |
+40°C |
| Min. temperature |
-25°C |
| Misc Attribute |
LS-S02-230AFT-ZBZ/X |
| Number of contacts as change-over contact |
0 |
| Number of contacts as normally closed contact |
2 |
| Number of contacts as normally open contact |
0 |
| Number of safety auxiliary contacts |
2 |
| Output electronic |
FALSE |
| Rated operation current Ie at AC-15, 125 V |
6A |
| Rated operation current Ie at AC-15, 230 V |
6A |
| Rated operation current Ie at AC-15, 24 V |
6A |
| Rated operation current Ie at DC-13, 125 V |
0.8A |
| Rated operation current Ie at DC-13, 230 V |
0.3A |
| Rated operation current Ie at DC-13, 24 V |
3A |
| Suitable for safety functions |
TRUE |
| Switching current (max.) |
6A |
| Switching function |
Slow-action switch |
| Switching function latching |
FALSE |
| Switching Voltage |
400V |
| Type of control element |
None |
| Type of electric connection |
Cable entry metrical |
| Type of interface |
None |
| Type of interface for safety communication |
None |
| Width |
60mm |
| Width sensor |
60mm |
| With status indication |
FALSE |
