EAO 82-6552.1134 22mm Illum PB Alu Flush/flush Screw Mom. Ag Ring Green 24VAC/DC

EAO 82-6552.1134 is an illuminated pushbutton measuring 22 mm in diameter, crafted from aluminium with a flush mounting style on both the actuator and bezel. This component features a screw terminal connection and employs momentary operation with silver contacts, offering reliable performance for applications requiring temporary engagement. The pushbutton is designed with a green ring illumination and is compatible with a 24 V AC/DC power supply, making it suitable for use in control panels, industrial machinery, and automated systems.

Type	Pushbutton
Contact Configuration	SPNO
Switch Function	Off-(On)
Current Rating	3A
Mounting	Panel
Illumination	Green
Panel Cutout Dimensions	22
Approbations	Cb, Ccc, C Ul, Ul
Climate Resistance	Damp Heat, 21 Days According To Iec 60512-11
Conformities	Ce, 2011 / 65 / Ec (rohs), 2014 / 35 / Eu (lvd)
Contacts Concat	1 C
Contacts Material	Silver
Electrical Lifetime	50 000 Cycles Of Operation
Erp Ehq Custom Number	8536.5000
Erp Ehq Source Country	Ch
Front Bezel Material	Aluminium
Front Bezel Shape	Flush
Front Dimension Concat	Ø 25mm
Front Form	Round
Illumination Colour Concat	Green
Ip Front Protection	Ip65, Ip67
Lens Colour	Nature
Lens Illumination	Illuminated
Lens Material	Aluminium
Lens Shape	Flush
Mounting Cut Out Dps Concat	Ø 22mm
Operating Concat	24 V / 7mA
Operating Current Concat	7mA
Operating Temperature	– 30 °c … + 70°C
Operating Voltage 1 Concat	24 V
Operating Voltage Concat	24 V Ac/dc
Output Hsd	Yes
Pollution degree	2, According To En Iec 60947-1
Shock Resistance	Max. 500 M / S² As Per Iec 60068-2-27
Switching Action Concat	Momentary
Switching System	Snap-action Switching Element
Terminal Concat	Screw terminal
Thermal Current Ith	5 A
Vibration Resistance	10 … 500 Hz, Amplitude 1.5 Mm P-p According To Iec 60068-2-6
Weight	0.018
