The Dobot Hexplorer 6-Legged Bionic Hexapod Robot is a professional mobile robotics platform, designed for research, education, inspection and field applications. Its six-legged design provides stable movement, enabling operation on uneven terrain, slopes up to 40° and obstacles up to 20cm, with a maximum speed of 1.8 m/s. It is suitable for environments including grass, sand, gravel, wet surfaces and stairs.
The platform integrates onboard sensing and autonomous control for real-time terrain adaptation. It features an x86 motion control PC and an ARM-based AI processor delivering up to 40 TOPS, supporting navigation, obstacle avoidance and target tracking. Supplied with Ubuntu 22.04 and ROS2 Humble, it has an SDK with Python and C++ support for high-level and joint-level control. A modular expansion interface supports future integration of additional systems such as robotic arms, video transmission and automated charging.
- Suitable for research and education, guided tours, security patrol and inspections, exploration and rescue operations.
- Dimensions (standing) 863 x 470 x 480mm
- Net weight: 20kg
- Max walking speed: 1.8m/s
- Max obstacle height:20cm
- Rated payload: 10kg
- Max payload: 15kg
- Battery capacity: 504Wh
- Battery life: 2.5 hours
- Motor peak torque: 33Nm
- Computer platorm: GPU 40 TOPS
- Integrated speaker
- LiDAR: Livox Mid360
| Type |
Hexapod |
| Manufacturers Warranty |
1 Year |
| Control Mode |
Remote Control and Autonomy |
| Max speed |
1.8m/s |
| Operating Temperature |
-10 to 40°C |
| Payload (Continuous) |
10kg |
| Payload (Maximum) |
15kg |
| Running Time |
2.5 hours |
| Weight |
20kg |
