Connfly DS1024-1*4RF1 SIL Socket 1 Row 4 Pins Standard 1 piece

Connfly
Standard range
Order Code:

08-8036

Brand: Connfly MPN: DS1024-1*4RF1 EAN-13: 2050009086411
Qty Unit Price (Ex VAT)
1+ £0.069
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
164 in stock, despatched in 4 working days

The Connfly DS1024-1*4RF1 is a single-row SIL socket with four pins per row, designed for standard applications. It is typically used for reliable and secure connections in electronic circuits. This component is commonly supplied in tube packaging for convenient handling and storage.
Type SIL socket (standard)
Case material PBT
Connection Solder pins
Connector orientation Parallel (to the PCB)
Connector type Power strip, right angle
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (W x H) 2.5 mm x 8.5 mm
Factory colour Black
Height 8.5mm
Manufacturer part # DS1024-1*4RF1
Max. temperature 105°C
Min. temperature -40°C
Misc Attribute DS1024-1*4RF1
No. of rows 1
Nominal current 1A
Nominal current - rounded value 1A
Packaging type Tube
Pin length (PCB) 3.3mm
Pin shape Rectangular
Pins per row 4
Separable No
Total number of pins 4
Width 2.5mm
