Connfly DS1023-2*9SF1-1 SIL Socket 2 Rows 9 Pins Per Row Standard Tube

Connfly
Extended range
Order Code:

08-8032

Brand: Connfly MPN: DS1023-2*9SF1-1 EAN-13: 2050009086480
Qty Unit Price (Ex VAT)
1+ £0.170
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderPlease contact us for lead time

Connfly manufactures the DS1023-2*9SF1-1 SIL socket, featuring 2 rows with 9 pins each. This standard socket is typically used in electronic applications for secure, reliable board-to-board connections. It is supplied in a single piece within a tube.
Type SIL socket (standard)
Case material PBT
Connection Solder pins
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Gold plated
CS 2.54mm
Dim (W x H) 5 mm x 8.5 mm
Factory colour Black
Height 8.5mm
Manufacturer part # DS1023-2*9SF1-1
Max. temperature 105°C
Min. temperature -40°C
Misc Attribute DS1023-2*9SF1-1
No. of rows 2
Nominal current 1A
Nominal current - rounded value 1A
Packaging type Tube
Pin length (PCB) 3mm
Pin shape Rectangular
Pins per row 9
Separable No
Total number of pins 18
Width 5mm
