Bulgin PX0412/10P 400 Series Buccaneer 10 Pole Front Panel Mount Connector Plug

The Bulgin PX0412/10P is a sealed circular front panel mounting connector from the 400 Series Buccaneer range, designed for dependable power and signal connections in demanding industrial, marine and outdoor environments.

Featuring 10 plug contacts, a single-hole fixing panel-mount body and compatibility with 400 Series Buccaneer flex cable connectors, this connector delivers secure mating and excellent protection against dust, water and harsh operating conditions.

Features

• 400 Series Buccaneer front panel mounting connector
• 10 plug contacts
• Single-hole fixing panel-mount body
• Contacts supplied separately
• IP68 rated when mated, tested at 10m depth for 2 weeks
• IP69K rated for high-pressure washdown environments
• Gold-plated contact system for reliable electrical performance
• 2.5mm contact engagement for electrical integrity
• Flame-retardant polyamide housing (UL94 V-0)
• Compatible with PX0410, PX0400 and PX0402 400 Series Buccaneer flex cable connectors

Electrical Specifications

• Number of contacts: 10
• Current rating: 1A
• Voltage rating: 50V AC/DC
• Contact resistance: <5mΩ
• Insulation resistance: >10⁶MΩ @ 500VDC
• AC breakdown voltage: 2.5kV

Mechanical & Environmental

• Connector type: Front panel mounting connector
• Contact engagement: 2.5mm
• Operating temperature: -40°C to +80°C
• Contact accommodation: 24 to 28 AWG for 10-contact versions
• Termination: Crimp or solder contacts, supplied separately
• Housing material: Polyamide
• Flammability rating: UL94 V-0
• Environmental protection: IP68 and IP69K
• Salt mist resistance: EN60068-2-52 Test Kb, Marine Severity Level 1

Applications

• Industrial control and automation systems
• Outdoor power and signal connections
• Marine electrical equipment
• Instrumentation and monitoring systems
• Transportation equipment
• Harsh-environment power and signal interconnections
