Bourns 3314J-1-201E Cermet trimmer 0.25 W 200 Ω 210° 240° 1 pc Trimmers

Bourns 3314J-1-201E, also known as 2996261, is a cermet trimmer potentiometer designed for precision adjustments, featuring a resistance value of 200 ohms. Rated at 0.25 watts, this component offers a mechanical angle of 210 degrees and an electrical angle of 240 degrees, enabling fine-tuning in compact electronic circuits. The trimmer is suitable for a wide range of engineering applications including calibration in industrial controllers, frequency adjustable resistors in communication devices, and offset or gain control in instrumentation. Its robust construction and reliable performance make it an ideal choice for environments where precise resistance adjustments are required.

Resistance	200Ω
Power Rating	0.25W
Connection	SMT
Content	1
Cross Section	2.35mm
Dimensions	(L x W x H) 4.5 x 4.5 x 2.55 mm
Electrical Angle	210°
Height	2.55mm
Length	4.5mm
Maximum Temperature	125°C
Mechanical Angle	240°
Minimum Temperature	-55°C
No. of rotations	1
Operation type	top
Product Type	Cermet trimmer
Temperature Coefficient	100ppm/K
Tolerance ±	20%
Width	4.5mm
