Bourns 3314J-1-104E Cermet trimmer 0.25 W 100 kΩ 210° 240° 1 pc

Bourns 3314J-1-104E is a precision-engineered cermet trimmer potentiometer designed for various electronic calibration and tuning applications. This model, also identified by the alternate description 2996260, offers a resistance value of 100 kO with a power rating of 0.25 watts. With an adjustment range between 210 and 240 degrees, it enables accurate and reliable performance in sensitive circuits. Commonly used in instrumentation, telecommunications, and medical devices, it allows for precise resistance adjustments necessary for optimal circuit function. Its durable construction ensures longevity and stability, making it a preferred choice for engineers requiring high-quality trimmer options.

Resistance	100kΩ
Power Rating	0.25W
Connection	SMT
Content	1
Cross Section	2.35mm
Dimensions	(L x W x H) 4.5 x 4.5 x 2.55 mm
Electrical Angle	210°
Height	2.55mm
Length	4.5mm
Maximum Temperature	125°C
Mechanical Angle	240°
Minimum Temperature	-55°C
No. of rotations	1
Operation type	top
Product Type	Cermet trimmer
Temperature Coefficient	100ppm/K
Tolerance ±	20%
Width	4.5mm
