Bourns 3266W-1-201LF cermet trimmer linear 0.25 W 200 Ω 4320° 1 pc

Bourns 3266W-1-201LF is a high-precision cermet trimmer, also known under the alternate description 2996152, designed to provide reliable performance in a range of electrical applications. This linear trimmer boasts a 200-ohm resistance and can carry up to 0.25 watts of power, making it suitable for fine-tuning circuits with precise impedance control. With a full adjustment range spanning 4320 degrees, it allows for highly granular resistance modifications, which is especially advantageous in sensitive calibration tasks. Typical applications of the 3266W-1-201LF include circuit boards for adjustment of analogue signals, sensor calibration, and setting reference voltages, which are critical in complex electronic systems. This trimmer is an ideal choice for engineers seeking a dependable solution for intricate circuit adjustments.

Type	Cermet Trimmer
Resistance	200Ω
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	Solder pins
Content	1
Cross Section	2.54mm
Dimensions	(L x W x H) 6.71 x 4.5 x 7.24 mm
Electrical Angle	4320°
Height	7.24mm
Length	6.71mm
Maximum Temperature	125°C
Minimum Temperature	-55°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.5mm
