Bourns 3224W-1-201E Cermet trimmer linear 0.25 W 200 Ohm 4320 degrees 1 pc

Bourns 3224W-1-201E is a cermet trimmer, classified under the product category, carrying the alternate description 2996136. This precision component offers a resistance of 200 ohms and is designed to handle a power rating of 0.25 watts. Its linear rotary adjustment extends over 4320 degrees, enabling fine tuning in circuits requiring meticulous calibration. This single piece component is frequently utilised in electronic applications such as tuning circuits, signal conditioning, and feedback control systems, where precise resistance settings are crucial. Its reliability and precise adjustability make it suitable for use in sophisticated engineering projects demanding high-performance trimmer capabilities.

Type	Cermet Trimmer
Resistance	200Ω
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Top
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	2.5mm
Dimensions	(L x W x H) 4.8 x 3.5 x 5.3 mm
Electrical Angle	4320°
Height	5.3mm
Length	4.8mm
Maximum Temperature	150°C
Minimum Temperature	-65°C
Operation type	top
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	3.5mm
