Bourns 3224J-1-103E Cermet trimmer linear 0.25 W 10 kΩ 4320 ° 1 pc

Bourns 3224J-1-103E, also known as part number 2996125, is a cermet trimmer potentiometer with a resistance value of 10 kO and a linear taper, designed to handle a power rating of 0.25 watts. This component features a precise rotational adjustment with a full-scale angle of 4320 degrees, facilitating fine-tuning in electronic circuits. It is typically utilised in applications requiring adjustable resistance settings, such as in calibration tasks, sensors for feedback control systems, or as a variable resistor in analogue electronic design. Its robust cermet construction ensures reliability and stability, making it suitable for both industrial and consumer electronic products.

Type	Cermet Trimmer
Resistance	10kΩ
Tolerance	± 10%
Power Rating	0.25W
Adjustment Type	Side
Number of Turns	12
Pitch	2.54mm
Connection	SMT
Content	1
Cross Section	4.8mm
Dimensions	(L x W x H) 4.8 x 4.6 x 3.71 mm
Electrical Angle	4320°
Height	3.71mm
Length	4.8mm
Maximum Temperature	150°C
Minimum Temperature	-65°C
Operation type	side
Resistance characteristic	linear
Temperature Coefficient	100ppm/K
Tolerance ±	10%
Width	4.6mm
