BKL 10120787 SIL socket 1 row 7 Pins standard 1pc(s) tray

BKL Electronic's SIL socket (standard) features a single row with 7 pins, making it ideal for compact electronic applications. It's commonly used in PCBs for connecting components securely. This reliable and efficient part is suitable for various electrical projects and prototyping needs.

Pitch	2.54mm
No. of Rows	1
No. of Ways	7
Case Material	Nylon (NL)
Connection	Print
Connector orientation	Perpendicular (to the PCB)
Connector Type	Power strip, straight
Contact Finish	Gold plated
CS	2.00mm
Factory colour	Black
Height	4.30mm
Maximum Temperature	+105°C
Min. temperature	-40°C
Nominal Current	2A
Nominal current - rounded value	2A
Nominal Voltage	500V
Packaging Type	Tray
Pin length (PCB)	2.40mm
Pin shape	Rectangular
Pins per row	7
Separable	No
Socket depth	2.40mm
Type	SIL socket (standard)
