BKL 10120202 Male Header 2.54mm Pitch Straight 1 x 8-pole 6.8mm Pins

BKL 10120202 Male Header 2.54mm Pitch Straight 1 x 8-pole 6.8mm Pins

BKL
Order Code:

54-5066

Brand: BKL MPN: 10120202

Discontinued


BKL Electronics 10120202 For vertical mounting as a cable connector, PCB connector strip or with option jumpers. For printed circuit boards, flat cable connectors, etc. The insulation is notched between each pin making it easy to cut the strips into intermediate lengths.


  • Gold-plated
  • Contact material: Gold plated
  • Contact resistance: Max 20 mΩ
  • Content: 1 pc
  • Dimensions, height: 12.6mm
  • Dimensions, length: 20.32mm
  • Dimensions, width: 2.54mm
  • Grid pitch: 2.54mm
  • Manufacturer part No.: 10120202
  • Nominal current: 3A
Type Header
Number of Positions 8
Pitch 2.54mm
Number of Rows 1
Mouning Orientation Straight
Connection Through hole
