Binder 99-9480-100-08 Male 3-4mm 8 Pin Cable Mount Bayonet with Solder Terminal

An 8-pin male subminiature panel mount bayonet connector with a 3 to 4mm outlet and solder terminals.

• Number of poles: 8
• Connector locking system: Bayonet-locking
• Termination: solder
• Wire gauge (mm): 0,14 mm²
• Wire gauge (AWG): 26
• Cable outlet: 3 - 4 mm
• Degree of protection: IP 40
• Mechanical operation: >500 mating cycles
• Upper temperature: +85 °C
• Lower temperature: -40 °C
• Rated voltage: 125 V
• Rated impulse voltage: 1500 V
• Pollution degree: 1
• Overvoltage category: II
• Material group: III
• Rated current (40°C): 1 A
• Volume resistivity: ≤ 3 mΩ
• Material of contact: CuSn (bronze)
• Contact plating: Au (gold)
• Material of contact body: PA (UL 94 V-0)
• Material of housing: PA (UL 94 HB)

Type	Panel Mount Male
Number of Contacts	8
Connector Size	18.5 mm dia
Gender	Male
Cable Diameter	3 to 4mm
Contact Material	CuSn
Contact Plating	Gold
Current Rating	1A
IP Rating	IP40
Mounting Type	Cable
Nominal Voltage	125V
Termination	Solder
