Adels-Contact 125205 Screw Terminal 5 Pins Flexible/Fixed 6 mm² Ecru

Adels-Contact
Standard range
Order Code:

11-1985

Brand: Adels-Contact MPN: 125205 EAN-13: 2050000569852
Qty Unit Price (Ex VAT)
1+ £0.771
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
245 in stock, despatched in 4 working days

The Adels-Contact 125205 is a screw terminal suitable for both flexible and fixed 6 mm² cables, featuring five pins. Manufactured by Adels-Contact, this ecru connector meets EU standards and is commonly used for secure electrical connections. It is ideal for lustre terminal applications where reliable and durable connections are essential.
Connection Screws
Cross section 6.0mm²
Cross section (flexible) (max.) 6mm²
Cross section (inflexible) (max.) 6mm²
Factory colour Ecru
Insulation material PA 6.6
Manufacturer part # 125205
Material (details) Polyamide 6
Misc Attribute 1000/5
Nominal current 25A
Nominal current - rounded value 25A
Nominal current (details) 25A
Nominal voltage 500V
Nominal voltage (details) 500V
Number of pins 5
RoHS-compliant Yes
Temperature range Continuous usage temperature +100 °C, short-term +160°C
Type Screw terminal
Wire protection No
