GW Instek LCR-6002 LCR Meter 999999 Counts High Precision

GW Instek introduces the brand new high precision LCR meter─LCR-6000 series, which, with five models, has a test frequency range extending from 2kHz/20kHz/100kHz/200kHz/300kHz (maximum) and with 0.05% basic accuracy. The compact size design, 2U height and 1/2 rack, is one of the practical features of the series which is the optimum space saver suitable for either bench top or system rack. The compacted LCR-6000 series with abundant features is absolutely the excellent tool for R&D, production test, IQC, etc. on implementing each test stages for passive components.

Type	RLC circuit
Display Counts	999999
Basic accuracy	0.05%
Calibrated to	Manufacturer's standards (no certificate)
Dim	(L x W x H) 312 x 265 x 107 mm
Display	Digital
Height	107mm
Inductivity reading range	0.00001 µH - 9999.99
Length	312mm
Misc Attribute	LCR-6002
Power supply (details)	90 - 250V AC
Reading frequency	10 Hz - 2kHz
Reading range - capacity	0.00001 pF - 9999.99mF
Reading range - resistance	99.9999 0.00001 ΩMΩ
Width	265mm
