The Siemens 6ED1052-1HB08-0BA2 is a programmable logic controller designed for use with 24 V DC and 24 V AC. This PLC controller is known for its reliability and efficiency in automating control processes. It is typically used in industrial automation applications, such as assembly lines, machinery control, and production systems.
| Type |
PLC controller |
| Certification |
UL approval. · FM-approved · VDE 0631 · IEC 61131 |
| Degree of protection (IP) |
IP20 |
| Depth |
60mm |
| Dim |
(L x W) 90 mm x 71.50 mm |
| Display |
Yes |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Fitting type (details) |
On top hat rail 35 mm, 4 division units wide |
| Height |
90mm |
| Interference suppression |
Conforms to EN 55 011 (limiting value class B) |
| Length |
90mm |
| Manufacturer part # |
6ED10521HB080BA2 |
| Max. ambient temperature |
+55°C |
| Max. operating voltage |
28.8V DC |
| Min. ambient temperature |
-20°C |
| Min. operating voltage |
20.4V DC |
| Misc Attribute |
6ED1052-1HB08-0BA2 |
| No. of inputs (max.) |
8 |
| No. of outputs (max.) |
4 |
| No. of relay outputs (max.) |
4 |
| Number of analogue inputs |
0 |
| Number of analogue outputs |
0 |
| Number of digital inputs |
8 |
| Number of digital outputs |
4 |
| Number of HW-interfaces industrial Ethernet |
1 |
| Number of HW-interfaces other |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
0 |
| Number of HW-interfaces wireless |
0 |
| Number of interfaces PROFINET |
0 |
| Operating voltage |
20.4 - 28.8 V DC |
| Power backup type |
480h |
| Short-circuit-proofing |
No |
| Switching Current |
10A |
| Timer |
Yes |
| Voltage type (supply voltage) |
AC/DC |
