Phoenix Contact 2961312 REL-MR pieceB Relay 24V DC 16A 1 Change-Over

Image Representative of Range

Phoenix Contact 2961312 REL-MR pieceB Relay 24V DC 16A 1 Change-Over

Phoenix Contact
Standard range
Order Code:

12-7228

Brand: Phoenix Contact MPN: 2961312 EAN-13: 2050000262838
Qty Unit Price (Ex VAT)
1+ £3.46
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
201 in stock, despatched in 4 working days

The Phoenix Contact REL-MR-24DC/21HC is a PCB relay designed for 24 V DC applications, capable of handling up to 16 A with 1 change-over contact. It is built according to standards such as IEC 60255 and DIN EN 50178, suitable for load switching tasks in various industrial environments. This pluggable mini relay is ideal for use in control panels and machinery where reliable electrical isolation and signal switching are required.
Height 29mm
Switching Current 16A
Type PCB relay
Width 12.7mm
Coil nominal voltage 24V DC
Connection Solder pins
Contact material AgNi
Contact type 1 change-over
Control mode monostable, 1 coil
Depth 15.7mm
Dim (W x H x D) 12.7 x 29 x 15.7 mm
Max. switching capacity 4000VA
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute REL-MR- 24DC/21HC
Nominal voltage (details) 24V DC
Resistance (coil) 1440Ω
Switching current (max.) 16A
Switching voltage
250 V (AC/DC)
