LeCroy ADP305 Differential probe, 1400V, 100MHz

The LeCroy ADP305 Differential Probe, 1400V, 100MHz is safe, easy-to-use and ideally suited for measuring power electronics, while this specific model has been designed for measuring the high-speed floating voltages found in today’s high-speed power electronics

The attenuation, offset, and bandwidth limit are additionally all controlled from the oscilloscope front panel, or by using the remote control commands. This means the complete measurement setup can be saved and recalled by the oscilloscope, and all measurement values will be correct. The scope provides power to the probe, so there is no need to worry about a separate power supply or changing batteries. Meanwhile, the ADP30X offset can be easily set to zero by pushing a button in the oscilloscope's coupling menu, even when connected to live circuits, making it easy to get accurate measurements.

Overall, the LeCroy ADP305 Differential Probe is in a field of its own and is also compatible with LC Series, LT Series, WS 400 Series, WS Xs Series, WR6000(A) Series, WR Xi Series, WP 900 Series, WP7000(A) Series.

• Easy-to-use
• ProBus system
• Full remote control
• Overall Length: 2 meters
• 1,000VRMS common mode voltage
• 1,400Vpeak differential voltage
• EN61010 Cat III
• 80dB CMRR at 50/60Hz
