LappKabel 0102002 HEAT 260 SC Single Core Cable 20 (19) AWG Blue

Image Representative of Range

LappKabel 0102002 HEAT 260 SC Single Core Cable 20 (19) AWG Blue

LappKabel
Standard range
Order Code:

63-5362

Brand: LappKabel MPN: 0102002 EAN-13: 2050001427335
Qty Unit Price (Ex VAT)
1+ £1.85
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
98 in stock, despatched in 4 working days

This single core cable from LappKabel is suitable for use in the most extreme conditions.


  • AWG (max): 20
  • Cable features: Heat-resistant, Oil-resistant, Acid-resistant
  • Cable Type: ÖLFLEX® HEAT 260 SC Heat-resistant cable
  • Colour: Blue
  • Cross section 1 x 0.57mm²
  • Insulation material: Polytetrafluoroethylene (PTFE)
  • Max. temperature range (fixed installation): +260°C
  • Min. temperature range (fixed installation): -190°C
  • No. of leads 1
  • Nominal voltage: 500V
  • Nominal voltage U0: 300V
  • Outside diameter: 1.47mm
  • Sold per metre: Yes
  • Test voltage: 3400V
  • Manufacturer's part 0102002

This cable will be supplied in one continuous length, subject to the maximum reel size. For example, an order for 7 metres of cable will result in a single 7-metre cable being supplied, not 7 one-metre lengths.
Conductor Stranding N/A
Insulation material Polytetrafluoroethylene (PTFE)
Cable Diameter 1.47mm
Cable Diameter (AWG) 20AWG
Colour Blue
Conductor Cross-section 1 x 0.57mm²
Length Sold per metre
Sold by Metre Yes
Standards/Test Marks N/A
