The Eaton N3-4-630 Circuit Breaker is designed for managing electrical circuits with a maximum switching voltage of 690 V AC. It is typically used in electrical systems to protect and control circuits in both domestic and industrial applications. With precision engineering, this circuit breaker ensures reliable performance and safety in various operational environments.
| Type |
Circuit breaker |
| Colour control element |
Black |
| Conditioned rated short-circuit current Iq |
0kA |
| Connection |
Screws |
| Degree of protection (IP), front side |
IP20 |
| Degree of protection (NEMA) |
Other |
| Depth |
159mm |
| Device construction |
Built-in device fixed built-in technique |
| Height |
275mm |
| Interlockable |
TRUE |
| IP rating |
IP20 |
| Max. rated operation voltage Ue AC |
690V |
| Misc Attribute 1 |
N3-4-630 |
| Misc Attribute 2 |
3 |
| Motor drive integrated |
FALSE |
| Motor drive optional |
TRUE |
| Mounting Type |
Fixed |
| No. of pins |
4-pin |
| Number of auxiliary contacts as change-over contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of Poles |
4 |
| Number of switches |
1 |
| Rated operating voltage |
690-690V |
| Rated operation power at AC-23, 400 V |
315kW |
| Rated operation power at AC-3, 400 V |
0kW |
| Rated permanent current at AC-21, 400 V |
0A |
| Rated permanent current at AC-23, 400 V |
0 |
| Rated short-time withstand current lcw |
12kA |
| RoHS-compliant |
Yes |
| Suitable for distribution board installation |
TRUE |
| Suitable for floor mounting |
TRUE |
| Suitable for front mounting 4-hole |
FALSE |
| Suitable for front mounting centre |
FALSE |
| Suitable for intermediate mounting |
TRUE |
| Switching power at 400 V |
0kW |
| Switching voltage (max.) |
690V AC |
| Type of control element |
Rocker lever |
| Type of electrical connection of main circuit |
Screw connection |
| Version as emergency stop installation |
TRUE |
| Version as main switch |
TRUE |
| Version as maintenance-/service switch |
TRUE |
| Version as reversing switch |
FALSE |
| Version as safety switch |
FALSE |
| Voltage release optional |
TRUE |
| Width |
185 |
| With pre-assembled cabling |
FALSE |
