Panasonic TX2-9V 2A 9VDC DPDT PCB Signal Relay TX Series

Order Code:

60-1334

  Copy to clipboard
( Write a review )
Brand: Panasonic  Copy to clipboard MPN: TX2-9V  Copy to clipboard
 Report an error

Discontinued

This 2A 9V DC signal relay has the capacity to handle high surge voltages and also has a high breakdown voltage. The relays are of the 2 form C (DPCO) type and function as single side stable types. The compact size of this relay makes it suitable for through hole PCB mounting.


  • Compact body
  • High surge resistance
  • High reliability contacts
  • Outstanding vibration and shock resistance
  • Sealed construction allows automatic washing
Contact Configuration DPDT
Coil Voltage (DC) 9V
Coil Current 15.5mA
Coil Resistance 579Ω
Switching Voltage Max (DC) 220V
Switching Power 62.5VA
Mounting Type PCB
Operating Temperature -40 to +85°C
Height 8.2mm
Length 15mm
Width 7.4mm
Switching Current Max 2A

Questions


*Question functionality currently disabled


23 June 2019 Question by: Rapid Customer | Product code: 60-1334
Q. the description says DPDT but the technical details says DPCO?
A. Hi Paul, thank you for your question. A DPCO is schematically equivalent to DPDT. Some suppliers use DPCO or DPDT.

Reviews


Be the first to submit a review
