Hongfa HFD2/005-S-D pieceB Relay 5V 3A 2 Change-Overs 1 piece

Image Representative of Range

Hongfa HFD2/005-S-D pieceB Relay 5V 3A 2 Change-Overs 1 piece

Hongfa
Standard range
Order Code:

09-3990

Brand: Hongfa MPN: HFD2/005-S-D EAN-13: 2050001760784
Qty Unit Price (Ex VAT)
1+ £1.80
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
141 in stock, despatched in 4 working days

Hongfa's HFD2/005-S-D PCB relay operates at 5 V DC with a 3 A current capacity and features two change-overs. This mini relay is designed for printed circuit board mounting, making it suitable for compact electronic devices. It is commonly used in applications requiring reliable switching and control of low-power circuits.
Height 10.6mm
Length 20.2mm
Type PCB relay
Width 10.2mm
Coil nominal voltage 5V DC
Connection Solder pins
Contact material Ag-AuAg8
Contact type 2 change-overs
Control mode monostable, 1 coil
Dim (L x W x H) 20.2 x 10.2 x 10.6 mm
Max. pick-up voltage 11.5V DC
Max. temperature +85°C
Min. pick-up voltage 4V DC
Min. temperature -40°C
Misc Attribute HFD2/005-S-D
Resistance (coil) 167Ω
RoHS-compliant Yes
Switching current (max.) 3A
