Bernstein's 6075685119 Safety button is used for emergency power off applications. This robust main switch is designed for controlling and stopping machinery in urgent situations. It ensures safety by providing immediate shutdown capability in hazardous scenarios.
| Type |
Safety button |
| Ambient temperature |
-25-70°C |
| Coating housing |
Uncoated |
| Construction type housing |
Cuboid |
| Cross-/short circuit identification possible |
TRUE |
| Degree of protection (IP) |
Other |
| Degree of protection (NEMA) |
4 |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Height of sensor |
15mm |
| Housing Material |
Plastic |
| Length of sensor |
36mm |
| Max. output current at protected output |
100mA |
| Mechanical mounting condition for sensor |
Other |
| Misc Attribute |
SRF-2/1/1-E0,25-U |
| Number of contact energized outputs with signalling function |
0 |
| Number of protected contact energized outputs |
0 |
| Number of protected semiconductor outputs |
2 |
| Number of semiconductor outputs with signalling function |
1 |
| Performance level according to EN ISO 13849-1 |
Level e |
| Protected switch distance OFF |
25mm |
| Protected switch distance ON |
10mm |
| Rated supply voltage DC |
24-24V |
| SIL according to IEC 61508 |
3 |
| Suitable for safety functions |
TRUE |
| Switching distance |
13mm |
| Type of actuation |
Transponder |
| Type of electric connection |
Cable with connector |
| Type of switching output |
PNP |
| Voltage type |
DC |
| Width sensor |
26mm |
| With monitoring function downstream switching devices |
FALSE |
| With status indication |
TRUE |
