ABB S 203 M-B 40 40A 3/P Circuit Breaker 10KA B

A 3-pole miniature circuit breaker from ABB that has type B characteristics. The 40A circuit breaker is ideal for applications where protection against low level short circuit faults in control wiring is desired. Instantaneous trip is 3 to 5x continuous rating of device (In). Applications include PLC wiring, business equipment, lighting, appliances and some motors.

• System Pro M Compact Series S 200
• Low magnetic trip point
• Clear contact position indication in red/green (real CPI)
• Unique, patented twin terminal with captive screws
• Increased opening for cables up to max. 35 mm², finger-proof (IP20)
• Busbar slot in the back for best visibility during installation
• High performance at an increased rated voltage for marine and industrial applications
• Individual product identification code
• Approved acc. to IEC/EN 60898-1, IEC/EN 60947-2 and UL 1077/CSA 22.2 No. 235 for global use
• Catalogue description: Miniature Circuit Breaker - S200M - Tripping characteristic B
• Supplied in 3-pole
• Supplied with power rating of 40A
• Product type: S203M-B40
• ABB Part: 2CDS273001R0405
