FTCAP LFB15306340066 15000µF -10+30% 63V Solder Tag Aluminium Elect Capacitor

This 63V 15,000µF electrolytic capacitor is from the LFB series from Fischer and Tausche and gives high capacitance values with a long service life. Typical applications for this capacitor include standard and switch mode power supplies, telecommunications, audio and HiFi systems and computer equipment.

• High capacitance
• Long life
• All internal contacts welded
• Stud mounting
• Solder terminals
• Includes fixing nuts
• Dielectric strength 2500V
• Dimensions (Ø x H) 40 x 66mm
• Electrical capacity 15000µF
• Shrink-fit hose insulation
• Nominal voltage 63V DC
• Reverse polarity voltage 2V (max)
• DIN 41332/IEC 384-4
• Temperature range -40 to +85°C
• Thread size M8
