The Bernstein 6075685101 Safety button is used as an emergency power off button, featuring robust construction for reliable performance. Manufactured by Bernstein, this switch is designed to enhance safety in industrial applications. It is typically used to quickly shut down equipment in case of an emergency.
| Type |
Safety button |
| Ambient temperature |
-25-70°C |
| Coating housing |
Uncoated |
| Construction type housing |
Cuboid |
| Cross-/short circuit identification possible |
TRUE |
| Degree of protection (IP) |
Other |
| Degree of protection (NEMA) |
4 |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
None |
| Height of sensor |
15mm |
| Housing Material |
Plastic |
| Length of sensor |
36mm |
| Max. output current at protected output |
100mA |
| Mechanical mounting condition for sensor |
Other |
| Misc Attribute |
SRF-5/1/1-E0,25-H |
| Number of contact energized outputs with signalling function |
0 |
| Number of protected contact energized outputs |
0 |
| Number of protected semiconductor outputs |
2 |
| Number of semiconductor outputs with signalling function |
0 |
| Performance level according to EN ISO 13849-1 |
Level e |
| Protected switch distance OFF |
25mm |
| Protected switch distance ON |
10mm |
| Rated supply voltage DC |
24-24V |
| SIL according to IEC 61508 |
3 |
| Suitable for safety functions |
TRUE |
| Switching distance |
13mm |
| Type of actuation |
Transponder |
| Type of electric connection |
Cable with connector |
| Type of switching output |
PNP |
| Voltage type |
DC |
| Width sensor |
26mm |
| With monitoring function downstream switching devices |
FALSE |
| With status indication |
TRUE |
