Alpha 63250-01600/A5K rotary potentiometer 5 kΩ 0.05 W mono single turn

Taiwan Alpha 63250-01600/A5K is a rotary potentiometer designed for precision variable resistance applications. This component operates as a single-turn mono potentiometer, providing a resistance value of 5 kO with a power rating of 0.05 watts, making it suitable for low-power electronic circuits. As a slide potentiometer, its mechanism allows for smooth and reliable resistance adjustments, which are essential in fine-tuning the performance of electronic devices. Engineers typically employ this type of rotary potentiometer in audio equipment, signal processing circuits, and other applications requiring precise control over electrical variables. Additionally, the part's compact design and consistent performance over its lifecycle make it a valuable component for both consumer electronics and industrial control systems.

Type	Single turn rotary pot
Resistance	5kΩ
Power Rating	0.05W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	150V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	logarithmic
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
