Alpha 63250-01600/A1K APM6A1KM Rotary Potentiometer 0.05W 1kΩ Mono 1pc

Taiwan Alpha 63250-01600/A1K APM6A1KM Rotary Potentiometer is a precision-engineered component designed for variable resistance applications, offering a resistance value of 1 kO and accommodating a power rating of 0.05 watts. This single-turn rotary potentiometer is ideally suited for applications requiring fine-tuneable electrical resistance adjustment, such as audio equipment, signal processing, and instrumentation where precise control of electronic signals is necessary. Its durable construction and mono channel configuration make it a reliable choice for engineers needing robust performance in both industrial and consumer electronics. As a slide potentiometer, it provides a smooth and consistent adjustment mechanism, contributing to its versatility and widespread use in electronic circuit designs.

Type	Single turn rotary pot
Resistance	1kΩ
Power Rating	0.05W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	150V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	logarithmic
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
